FG-600E

Model:

FG-600E - FORTIGATE 600E NETWORK SECURITY

Detail:

FortiGate-600E 2 x 10GE SFP+ slots, 10 x GE RJ45 ports (including 1 x MGMT port, 1 X HA port, 8 x switch ports), 8 x GE SFP slots, SPU NP6 and CP9 hardware accelerated.

List Price:

US$ 6,900.00

Price:

US$4,258.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

SFP+ SFP RJ-45

Add to Cart

Specification

FG-600E Specification
Type	FORTIGATE 600E
Interfaces and Modules
10 GE SFP+ Slots	2
GE SFP Slots	8
GE RJ45 Interfaces	8
GE RJ45 Management Ports	2
USB Ports	2
RJ45 Console Port	1
Local Storage	NIL
Included Transceivers	2x SFP (SX 1 GE)
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	36 / 36 / 27 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP)	36 / 36 / 27 Gbps
Firewall Latency (64 byte, UDP)	2 μs
Firewall Throughput (Packet per Second)	40.5 Mpps
Concurrent Sessions (TCP)	8 Million
New Sessions/Second (TCP)	450,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)	20 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	7 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	10,000
SSL Inspection Throughput (IPS, avg. HTTPS)	8 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)	5,500
Application Control Throughput (HTTP 64K)	15 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total / Tunnel)	1024 / 512
Maximum Number of FortiTokens	5,000
Maximum Number of Registered FortiClients	2,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
System Performance — Enterprise Traffic Mix
IPS Throughput	10 Gbps
NGFW Throughput	9.5 Gbps
Threat Protection Throughput	7 Gbps
Dimensions and Power
Height x Width x Length	1.75 x 17.0 x 15.0 inches 44.45 x 432 x 380 mm
Form Factor	1 RU
AC Power Supply	100–240V AC, 60–50 Hz
Power Consumption (Average / Maximum)	129 W / 244 W
Current (Maximum)	6A @ 100V
Heat Dissipation	832 BTU/h
Redundant Power Supplies	optional
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	59 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

Q&A

What common troubleshooting steps are there for the Fortinet FG-600E?

Common troubleshooting includes checking physical connections, ensuring firmware is updated, and utilizing Fortinet's support resources for advanced issues.

What accessories are available for the Fortinet FG-600E?

Accessories include additional SFP modules, rack mount kits, and power cables. Consult Fortinet's accessory options for compatibility.

How does the Fortinet FG-600E compare with other Fortinet models?

The FG-600E offers a balance of performance and cost, fitting between entry-level and high-end models in the Fortinet Network Security Platforms.
