FG-600D

Model:

FG-600D - Fortigate 600D FG-600D Network Security Firewall

Detail:

2 x 10GE SFP+ slots, 8 x GE RJ45 ports, 8 x GE SFP slots, SPU NP6 and CP8 hardware accelerated, 120GB onboard SSD storage.

List Price:

US$ 4,950.00

Price:

US$2,205.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

SFP+ SFP RJ-45

Add to Cart

Specification

FG-600D Specification
Type	FORTIGATE 600D
Interfaces and Modules
Hardware Accelerated GE SFP Slots	2
Hardware Accelerated GE RJ45 Ports	8
GE RJ45 Management Ports	2
USB Ports (Client / Server)	1 / 2
Console Port	1
Onboard Storage	1x 120 GB SSD
Included Transceivers	2
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	36 / 36 / 24 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP)	36 / 36 / 24 Gbps
Firewall Latency (64 byte, UDP)	3 μs
Firewall Throughput (Packet per Second)	36 Mpps
Concurrent Sessions (TCP)	5.5 Million
New Sessions/Second (TCP)	270,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)	20 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	2.2 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	5,000
SSL Inspection Throughput (IPS, avg. HTTPS)	3.5 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)	2,400
Application Control Throughput (HTTP 64K)	9 Gbps
CAPWAP Throughput (1444 byte, UDP)	10 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	64
Maximum Number of FortiAPs (Total / Tunnel)	1024 / 512
Maximum Number of FortiTokens	1,000
Maximum Number of Registered FortiClients	2,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
System Performance — Optimal Traffic Mix
IPS Throughput	7 Gbps
System Performance — Enterprise Traffic Mix
IPS Throughput	4 Gbps
NGFW Throughput	3.8 Gbps
Threat Protection Throughput	3 Gbps
Dimensions and Power
Height x Width x Length	1.75 x 17 x 12.68 inches 44.45 x 432 x 322 mm
Form Factor	1 RU
AC Power Supply	100–240V AC, 60–50 Hz
Power Consumption (Average / Maximum)	126 W / 191 W
Current (Maximum)	110V/4A, 220V/2A
Heat Dissipation	650 BTU/h
Redundant Power Supplies	Supports FRPS-100
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	45 dBA
Operating Altitude	Up to 9,843 ft (3,000 m)
Compliance	FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

Q&A

What common troubleshooting steps are there for the FG-600D?

Common troubleshooting includes checking network connections, rebooting the device, and restoring factory settings if needed.

What accessories are available for the Fortinet FG-600D?

Accessories for the FG-600D include SFP+ transceivers, power supply units, and rack mount kits.

How does the Fortinet FG-600D compare with other similar products?

The FG-600D stands out with its high port density, hardware acceleration (SPU NP6 and CP8), and onboard SSD storage, offering superior performance at its price point.
