FG-1101E

FG-1101E Specification

Interfaces and Modules

Hardware Accelerated 40 GE QSFP+ Slots

2

Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots

4

Hardware Accelerated 10 GE SFP+ Slots / GE SFP Slots

4

Hardware Accelerated GE SFP Slots

8

Hardware Accelerated GE RJ45 Ports

16

GE RJ45 Management / HA Ports

2

USB Ports (Client / Server)

1 / 2

Console Port

1

Onboard Storage

2x 480 GB SSD

Included Transceivers

2x SFP (SX 1 GE)

System Performance — Enterprise Traffic Mix

IPS Throughput ²

12.5 Gbps

NGFW Throughput ^{2, 4}

9.8 Gbps

Threat Protection Throughput ^{2, 5}

7.11 Gbps

System Performance and Capacity

IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)

80 / 80 / 45 Gbps

IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP)

80 / 80 / 45 Gbps

Firewall Latency (64 byte, UDP)

2.76 μs

Firewall Throughput (Packet per Second)

67.5 Mpps

Concurrent Sessions (TCP)

8 Million

New Sessions/Second (TCP)

500,000

Firewall Policies

100,000

IPsec VPN Throughput (512 byte) ¹

48 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

20,000

Client-to-Gateway IPsec VPN Tunnels

100,000

SSL-VPN Throughput

8.4 Gbps

Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)

10,000

SSL Inspection Throughput (IPS, avg. HTTPS) ³

10 Gbps

SSL Inspection CPS (IPS, avg. HTTPS) ³

6,500

SSL Inspection Concurrent Session (IPS, avg. HTTPS) ³

780,000

Application Control Throughput (HTTP 64K) ²

26 Gbps

CAPWAP Throughput (HTTP 64K)

43 Gbps

Virtual Domains (Default / Maximum)

10 / 250

Maximum Number of FortiSwitches Supported

196

Maximum Number of FortiAPs (Total / Tunnel)

4,096 / 2,048

Maximum Number of FortiTokens

20,000

High Availability Configurations

Active-Active, Active-Passive, Clustering

Dimensions and Power

Height x Width x Length (inches)

3.5 x 17.44 x 17.62

Height x Width x Length (mm)

88.9 x 443 x 447.4

Weight

25.4 lbs (11.55 kg)

Form Factor (supports EIA/ non-EIA standards

Rack Mount, 2 RU

AC Power Input

100–240V AC, 50/60 Hz

Power Consumption (Average / Maximum)

222 W / 346 W

AC Current (Maximum)

6A@120V, 3A@240V

Heat Dissipation

1,181 BTU/h

DC Power Input (FG-1100E-DC)

--

DC Current (Maximum)

--

Redundant Power Supplies

Yes, Hot swappable

Operating Environment and Certifications

Operating Temperature

32–104°F (0–40°C)

Storage Temperature

-31–158°F (-35–70°C)

Humidity

10–90% non-condensing

Noise Level

66.7 dBA

Forced Airflow

Front to Back

Operating Altitude

Up to 7,400 ft (2,250 m)

Compliance

FCC ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB

Certifications

ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6
