FG-1500D

Model:

FG-1500D - Fortinet FG-1500D Network Security Firewall

Detail:

8 x 10GE SFP+ slots, 16 x GE SFP slots, 18 x GE RJ45 ports (including 16 x ports, 2 x management/HA ports), SPU NP6 and CP8 hardware accelerated, 480GB SSD onboard storage.

List Price:

US$ 1,870.00

Price:

US$805.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

SFP+ SFP RJ-45

Add to Cart

Specification

FG-1500D Specification
Type	FORTIGATE 1500D
Interfaces and Modules
Hardware Accelerated 10 GE SFP+ / GE SFP Slots	8
Hardware Accelerated GE SFP Slots	16
Hardware Accelerated 10 GE RJ45 Ports	—
Hardware Accelerated GE RJ45 Ports	16
GE RJ45 Management / HA Ports	2
USB Ports (Client/Server)	1 / 1
Console Port	1
Onboard Storage	2x 240 GB SSD
Included Transceivers	2x SFP+ (SR 10GE)
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte, UDP)	80 / 80 / 55 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP)	80 / 80 / 55 Gbps
Firewall Latency (64 byte, UDP)	3 μs
Firewall Throughput (Packet per Second)	82.5 Mpps
Concurrent Sessions (TCP)	12 Million
New Sessions/Second (TCP)	300,000
Firewall Policies	100,000
IPsec VPN Throughput (512 byte)	50 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	20,000
Client-to-Gateway IPsec VPN Tunnels	100,000
SSL-VPN Throughput	4 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	10,000
SSL Inspection Throughput (IPS, avg. HTTPS)	5.7 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)	3,100
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	800,000
Application Control Throughput (HTTP 64K)	16 Gbps
CAPWAP Throughput (1444 byte, UDP)	20 Gbps
Virtual Domains (Default / Maximum)	10 / 250
Maximum Number of FortiSwitches Supported	128
Maximum Number of FortiAPs (Total / Tunnel)	4,096 / 1,024
Maximum Number of FortiTokens	20,000
Maximum Number of Registered FortiClients	20,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
System Performance — Enterprise Traffic Mix
IPS Throughput	13 Gbps
NGFW Throughput	7 Gbps
Threat Protection Throughput	5 Gbps
Dimensions and Power
Height x Width x Length	3.5 x 17.24 x 21.81 inches 89 x 438 x 554 mm
Form Factor	Rack Mount, 2 RU
AC Power Supply	100–240V AC, 50–60 Hz
Power Consumption (Average / Maximum)	336 / 403.2 W
Heat Dissipation	1,375 BTU/h
Redundant Power Supplies	Yes, Hot swappable
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	59 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6

Q&A

What common troubleshooting steps should I know for the Fortinet FG-1500D?

Common steps include resetting the device, checking connection cables, and consulting the log files for error messages to identify issues.

What accessories are available for the Fortinet FG-1500D?

Accessories include additional SFP transceivers, rack mount kits, and redundant power supplies to enhance and maintain the device's functionality.

How does the Fortinet FG-1500D compare with similar products?

Compared to similar products, the FG-1500D stands out with its superior SPU NP6 and CP8 hardware acceleration, providing excellent performance for demanding network environments.
