C1111-8PLTEEA

Model:

C1111-8PLTEEA - Cisco 1100 Series Router

Detail:

ISR 1100 8P Dual GE SFP Router w/ LTE Adv SMS/GPS EMEA & NA

List Price:

US$ 1,998.00

Price:

US$1,557.00

Delivery:

1 Month Standard Lead Time
Need it sooner? Contact our sales team.

Tags:

Small Business Routers Router

Add to Cart

Shop Bundles or Accessories Recommended by Experts

Options

Ethernet Switch

US$ 1,557.00

- 1 +

C1111-8PLTEEA

ISR 1100 8P Dual GE SFP Router w/ LTE Adv SMS/GPS EMEA & NA

US$ 2,289.00

- 1 +

C9200-48P-E Cisco Catalyst 9200 48-port PoE+ Switch, equipped with Network Essentials for reliable power over Ethernet.

US$ 1,000.00

- 1 +

C9200L-24P-4G-E Cisco Catalyst 9200L 24-port PoE+ Switch featuring 4x1G uplink, part of the Network Essentials series.

US$ 2,696.00

- 1 +

C9200L-48P-4X-E Cisco Catalyst 9200L 48-port PoE+ Switch with 4x10G uplink, Network Essentials edition.

US$ 1,800.00

- 1 +

C9200L-48P-4G-E Cisco Catalyst 9200L 48-port PoE+ Switch with 4x1G uplink, offering Network Essentials.

US$ 2,696.00

- 1 +

C9200L-48P-4X-E Cisco Catalyst 9200L 48-port PoE+ Switch with 4x10G uplink, Network Essentials edition.

US$ 1,800.00

- 1 +

C9200L-48P-4G-E Cisco Catalyst 9200L 48-port PoE+ Switch with 4x1G uplink, offering Network Essentials.

US$ 1,065.00

- 1 +

C9200L-24T-4X-E Cisco Catalyst 9200L 24-port Data Switch with 4x10G uplink, Network Essentials version.

US$ 1,263.00

- 1 +

C9200-48P-A Cisco Catalyst 9200 48-port PoE+ Switch with Network Advantage for enhanced networking features.

Accessory Selected Combo Price

US$ 9,342.00

Add to Cart

Accessory Selected Combo Price

US$ 8,381.00

Add to Cart

C1111-8PLTEEA Overview

The Cisco C1111-8PLTEEA is a versatile and powerful integrated services router designed for small to medium-sized businesses. It combines robust routing, switching, security, and wireless capabilities in a compact and energy-efficient form factor. This router is ideal for branch offices seeking a reliable and secure connectivity solution with integrated LTE Advanced and GPS functionality.

Key Features:

High Performance: Enables concurrent data, voice, and video services with minimal performance degradation.
Comprehensive Security: Includes a built-in firewall, high-speed IPsec encryption (3DES and AES), and support for various VPN technologies (DMVPN, FlexVPN, GET VPN, EzVPN).
Integrated LTE Advanced: Offers reliable cellular connectivity with advanced LTE speeds and support for SMS/GPS.
Power over Ethernet (PoE): Provides power to connected devices such as IP phones and access points through PoE/PoE+ ports.
Unified Communications: Supports a wide range of unified communications features and applications.
Simplified Management: Offers centralized management of wired and wireless networks through a common console.

Technical Specifications:

Feature	Specification
Model	C1111-8PLTEEA
WAN Interfaces	1x GE, 1x GE/SFP combo
LAN Interfaces	8x GE (4x PoE, 2x PoE+)
LTE	LTE Advanced (CAT6), EMEA & NA
Wireless	N/A
USB Ports	1x USB 3.0 Type A, 1x USB 5-pin micro Type B console
DRAM	4GB
Flash Memory	4GB
Dimensions (H x W x D)	1.75 x 12.7 x 9.6 in. (44 x 323 x 244 mm)

Benefits for Your Business:

Enhanced Connectivity: Provides reliable primary or backup internet connectivity with integrated LTE Advanced.
Increased Productivity: Supports high-performance networking for critical business applications.
Strong Security: Protects your network and data with advanced security features.
Simplified Operations: Reduces IT overhead with centralized management and easy deployment.
Cost Savings: Consolidates multiple network devices into a single platform, lowering TCO.

This router is designed to meet the evolving needs of modern businesses by delivering a secure, reliable, and high-performance network foundation.

Specification

C1111-8PLTEEA Specification

C1111-8PLTEEA Specification
Description	ISR 1100 8P Dual GE SFP Router w/ LTE Adv SMS/GPS EMEA & NA
Physical Properties
Dimensions (H x W x D)	LTE models: H x W X D = 1.75 x 12.7 x 9.6 in. (44 x 323 x 244 mm) (includes rubber feet)
AC Input Power
Input voltage	Universal 100 to 240 VAC
Frequency	50-60 Hz
Input current	PoE not enabled: 0.82A maximum PoE enabled: 1.55A Maximum
Surge current	90 A peak and less than 8 Arms per half cycle
Ports
Micro USB Port	One RJ-45: Separate console port
USB port	USB 3.0 Type A host port USB devices supported: USB flash memory
Console port	One USB 5-pin micro Type B: Console management connectivity
10/100/1000 Gigabit Ethernet	Two GE ports allocated among RJ45 and SFP as: One combo port with 10/100/1000RJ-45 Ethernet port or SFP Ethernet port (labeled GE0/0/0) One dedicated 10/100/1000RJ-45 Ethernet port (labeled GE0/0/1)
Wireless VLANs	32 (encrypted and non-encrypted VLANs)
Wireless specifications	2x2 .11ac Wave 2
Default and maximum DRAM	4GB
Default and maximum flash	4GB
Inline PoE	4 ports for -8P PIDs, 2 ports for -4P PIDs 802.3af-compliant PoE or 802.3at-compliant PoE+
Acoustic for Cisco 1100 Series ISRs	Not Applicable - Fanless design
Approvals and compliance	Emission 47 CFR Part 15 CISPR 32 Edition 2 EN 300 386 V1.6.1 EN 55032:2012/ AC:2013 EN 55032:2015 EN61000-3-2 2014 EN61000-3-3: 2013 ICES-003 ISSUE 6:2016 KN 32: 2015 V-2/2015.04 V-3/2015.04 TCVN 7189: 2009 CNS13438: 2006 IEC 60950-1 EN 60950-1 UL 60950-1 CSA C22.2 No. 60950-1 Immunity CISPR24: 2010 + A1: 2015 EN 300 386 V1.6.1 EN55024: 2010 + A1: 2015 KN35: 2015 TCVN 7317: 2003
Environmental
Operating humidity	5 to 85% relative humidity
Operating temperature	32 to 104°F (0 to 40°C) Sea Level; 32 to 77°F (0°C to 25°C) at 10,000 ft 1.5°C derating per 1000 ft
Altitude in China	0-6560 ft (0-2000 m)
Altitude in all other countries	0-10,000 ft (0-3050 m)
Transportation and Storage
Nonoperating temperature	-40 to 158°F (-40 to 70°C)
Nonoperating humidity	5 to 95% relative humidity (noncondensing)
Nonoperating altitude	0 to 15,000 ft (0 to 4570m)
