AR0M0022BA00

AR0M0022BA00 Specifications

Type

AR2220, 3GE WAN(1GE Combo), 2 USB, 4 SIC, 2 WSIC, 1 DSP Slot, 150W AC Power

Software Version

V200R001C00 and later

Dimensions (W x D x H)

442.0 mm x 420.0 mm x 44.5 mm

Memory

2 GB

Flash

16 MB

Hard disk

None

Service and Router Unit (SRU)

Not supported

Network data encryption (SM1/2/3/4) card

Supported

Management interface

Supported

Console interface (RJ45)

Supported

Console interface (Mini USB)

Supported

USB 2.0 interface (host)

Supported

USB 2.0 interface (OTG)

None

Micro SD card (default)

Supported (2 GB)

Antenna interfaces

None

Service interfaces (standard configuration)

WAN interfaces: 2 GE electrical interfaces and 1 GE combo interface

LAN interfaces: none

Interface number

LAN interfaces: none

Extended slots

4 SIC slots and 2 WSIC slots

Power module type

Built-in AC power module

Rated voltage range

100 V AC/240 V AC, 50 Hz/60 Hz

Maximum voltage range

90 V AC to 264 V AC, 47 Hz to 63 Hz

RPS150

Not supported

PoE

Not supported

Maximum PoE power for PDs

None

PoE+ interfaces

None

Weight

7 kg (15.4 lb)

Mounting brackets

Standard configuration

Operating temperature

0°C to 45°C (32°F to 113°F)

Operating altitude

0-4000 m (0-13123 ft.)

Fan type

Built-in fans

Heat dissipation mode

Forcible air cooling

Installation mode

Rack mounting
