CISCO3945-SEC/K9

You would use a SM-NM-ADPTR Network Module Adapter (for SM Slot on Cisco 2900, 3900 ISR) with your EVM-HD-8FXS/DID to setup them in the Service Module Slot.

The HSEC-K9 license removes the curtailment enforced by the U.S. government export restrictions on the encrypted tunnel count and encrypted throughput. HSEC-K9 is available only on the Cisco 2921, Cisco 2951, Cisco 3925, Cisco 3945, Cisco 3925E, and Cisco 3945E. With the HSEC-K9 license, the ISRG2 router can go over the curtailment limit of 225 tunnels maximum for IP Security (IPsec) and encrypted throughput of 85-Mbps unidirectional traffic in or out of the ISR G2 router, with a bidirectional total of 170 Mbps. The Cisco 1941, 2901, and 2911 already have maximum encryption capacities within export limits.

Itnot only depends on your SPE module but also others: Each service-module slot offers high data-throughput capability: • Up to 4-Gbps aggregate toward the router processor. • Up to 2-Gbps aggregate to other module slots over the MGF. Each HWIC slot offers high-data-throughput capability: • Up to 1.6-Gbps aggregate toward the router processor. • Up to 2-Gbps aggregate to other module slots over the MGF. Each ISM slot offers high-data-throughput capability: • Up to 4-Gbps aggregate toward the route processor. • Up to 2-Gbps aggregate to other module slots over the MGF.

The HSEC-K9 license removes the curtailment enforced by the U.S. government export restrictions on the encrypted tunnel count and encrypted throughput. HSEC-K9 is available only on the Cisco 2921, Cisco 2951, Cisco 3925, Cisco 3945, Cisco 3925E, and Cisco 3945E. With the HSEC-K9 license, the ISRG2 router can go over the curtailment limit of 225 tunnels maximum for IP Security (IPsec) and encrypted throughput of 85-Mbps unidirectional traffic in or out of the ISR G2 router, with a bidirectional total of 170 Mbps. The Cisco 1941, 2901, and 2911 already have maximum encryption capacities within export limits.
