C9300L-24UXG2Q-10E

Model:
Cisco Catalyst 9300L-24UXG2Q-10E Switch
Detail:
Cisco Catalyst 9300 Series with advanced security, IoT, mobility, and cloud features.
Delivery:
1 Month Standard Lead Time
Need it sooner? Contact our sales team.
Tags:
Add to Cart

Specification

Specification

C9300L-24UXG2Q-10E Specification

C9300L-24UXG2Q-10E Specification

Product Description

Cisco Catalyst 9300L - Network Essentials - switch - 24 ports - managed - rack-mountable

Device Type

Switch - 24 ports - L3 - managed - stackable

Enclosure Type

Rack-mountable

Bundled Services

10 years Network Essentials

Subtype

Gigabit Ethernet

Ports

16 x 10/100/1000 (UPOE) + 2 x 40Gb Ethernet + 8 x 1/2.5/5/10GBase-T

Power Over Ethernet (PoE)

UPOE

Performance

Switching capacity: 352 Gbps
Switching capacity with stacking: 672 Gbps
Forwarding rate: 261.9 Mpps
Forwarding rate with stacking: 500 Mpps

Capacity

IPv4 routes: 32000
IPv6 routes: 16000
Multicast scale: 8000
QoS scale entries: 5120
ACL scale entries: 5120
VLANs supported: 4094
Switched virtual interfaces (SVIs): 1000

MAC Address Table Size

32000 entries

Jumbo Frame Support

9198 bytes

Features

Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, 16MB packet buffer, DiffServ Code Point (DSCP) support, MACsec support, Control plane protection (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), secure boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, Committed Information Rate (CIR), Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0, Cisco StackWise-320 technology

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6

Power

AC 100-240 V (50 - 60 Hz)

Power Redundancy

Optional

Dimensions (WxDxH)

17.5 in x 1.7 in x 19.2 in

Manufacturer Warranty

Limited lifetime warranty

General

Device Type

Switch - 24 ports - L3 - managed - stackable

Bundled Services

10 years Network Essentials

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

16 x 10/100/1000 (UPOE) + 2 x 40Gb Ethernet + 8 x 1/2.5/5/10GBase-T

Power Over Ethernet (PoE)

UPOE

PoE Budget

722 W

Performance

Switching capacity: 352 Gbps
Switching capacity with stacking: 672 Gbps
Forwarding rate: 261.9 Mpps
Forwarding rate with stacking: 500 Mpps

Capacity

IPv4 routes: 32000
IPv6 routes: 16000
Multicast scale: 8000
QoS scale entries: 5120
ACL scale entries: 5120
VLANs supported: 4094
Switched virtual interfaces (SVIs): 1000

MAC Address Table Size

32000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG

Encryption Algorithm

128-bit AES, 256-bit AES

Features

Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, 16MB packet buffer, DiffServ Code Point (DSCP) support, MACsec support, Control plane protection (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), secure boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, Committed Information Rate (CIR), Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0, Cisco StackWise-320 technology

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6

RAM

8 GB

Flash Memory

16 GB

Sta tus Indicators

Status

Expansion / Connectivity

Inte rfaces

16 x 1000Base-T RJ-45 60 W
2 x 40Gbit LAN uplink
1 x network stack device
1 x management (LAN) RJ-45
1 x console
1 x USB 2.0
8 x 1/2.5/5/10GBase-T RJ-45

Power

Power Device

Internal power supply - hot-plug

Installed Qty

1 (installed) / 2 (max)

Power Redundancy

Optional

Power Provided

1100 Watt

Voltage Required

AC 100-240 V (50 - 60 Hz)

Miscellaneous

MTBF

291,670 hours

Compliant Standards

CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35

Dimensions

Width

17.5 in

Depth

1.7 in

Height

19.2 in

Environmental Parameters

Min Operating Temperature

23 °F

Max Operating Temperature

113 °F

Humidity Range Operating

5 - 90% (non-condensing)

Min Storage Temperature

-40 °F

Max Storage Temperature

158 °F
