C8500L-8S4X

C8500L-8S4X Specification

Description

Cisco Catalyst 8500 Series 12-port SFP+, 8x1GE,4x10GE

Port density

4-port 1/10GE, 8-port 1GE

Max 1GE ports

12

Max 10GE ports

4

Max 40GE ports

0

Max 100GE ports

0

SD-WAN IPsec Throughput (1400Bytes, clear text)

Up to 19Gbps

SD-WAN IPsec Throughput (IMIX*, clear text**)

Up to 8.6Gbps

SD-WAN Overlay Tunnels scale

8000

IPv4 Forwarding Throughput (1400Bytes)

Up to 20Gbps

IPsec Throughput (1400Bytes, clear text**)

Up to 19Gbps

Number of IPsec SVTI Tunnels

4000

Number of ACLs per system

4000

Number of IPv4 ACEs per system

50K

Number of IPv4 Routes

3.5M w/ default 16GB

Number of IPv6 Routes

2.2M w/ default 16GB

Number of Queues

16K

Number of NAT Sessions

2M

Number of Firewall Sessions

2M

Number of VRFs

8000

Mechanical specifications

Dimensions (H x W x D)

1.73 x 17.50 in x 16.25 in

Rack Units (RU)

1RU

Input voltage

AC: 100 to 240 VAC

DC: -40 to -60 VDC

HVAC: 100 to 277 VAC

HVDC: 240 to 380 VDC

Operating temperature

32 to 104°F

(0 to 40°C)

Storage temperature

-40 to 150°F

(-40 to 70°C)
