C1-ASR1004/K9 Specifications |
|
Physical specifications Note: Depth applies to chassis edge-to-edge dimension and does not include protrusions such as card handles, power-supply handles, and cable management brackets. Refer to the applicable hardware installation guide for additional details. |
Height: 7 in. (177.8 mm) Width: 17.2 in. (437.4 mm) Depth: 18.15 in. (461.0 mm) Weight: ● 68.7 lb (31.16 kg) (with dual AC power supply, SPA blank covers, Cisco ASR 1000 Series 10-Gbps ESP [ASR1000-ESP10] or ASR 1000 Series 40-Gbps ESP [ASR1000-ESP-40], Cisco ASR 1000 Series Route Processor 1 [RP1] [ASR1000-RP1], two Cisco ASR 1000 Series 10-Gbps SIPs [ASR1000-SIP10] or ASR1000 Series 40-Gbps SIPs [ASR1000-SIP-40], and no SPAs) |
Default memory |
4-GB DRAM RP1 8-GB DRAM RP2 |
Number of SIPs or Ethernet line cards supported |
2 |
Shared port adapters |
8 SPA slots |
Ethernet port adapters |
N/A |
Cisco ASR 1000 Series ESP |
1 ESP slot |
Route processor |
1 route-processor slot |
Redundancy |
Software: Yes |
Built-in Gigabit Ethernet ports |
0 |
Built-in 10 Gigabit Ethernet port |
No |
Network interface module |
No |
Cisco ASR 1000 Series |
Cisco ASR 1004 |
ESP support |
Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10), noncrypto Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10-N), Cisco ASR 1000 Series 20-Gbps ESP (ASR1000-ESP20), and Cisco ASR 1000 Series 40-Gbps ESP (ASR1000-ESP40) |
ESP bandwidth |
10 to 40 Gbps |
ESP memory |
Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10) and ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10): 2‑GB DRAM default; 2‑GB DRAM maximum Cisco ASR 1000 Series 20-Gbps ESP (ASR1000-ESP20): 4‑GB DRAM default; 4‑GB DRAM maximum |
SIPs and Ethernet line cards |
Supports Cisco ASR 1000 Series 10-Gbps SIP Carrier Card (ASR1000-SIP10), Cisco ASR 1000 Series 40-Gbps SIP Carrier Card (ASR1000-SIP40), and ASR 1000 Fixed Ethernet Line Cards; two 10 GE + twenty 1 GE line cards (ASR1000-2T+20X1GE); and six 10 GE line cards (ASR1000-6TGE) |
Embedded hardware-based encryption |
Yes: On Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10) with up to 4 Gbps and on Cisco ASR 1000 Series 20-Gbps ESP (ASR1000-ESP20) with up to 8-Gbps crypto support throughput Note: No support on noncrypto Cisco ASR 1000 Series 10-Gbps ESP (ASR1000-ESP10-N) |
Minimum Cisco IOS XE Software release |
Cisco IOS XE Software Release 2.1 |
Rack-mounting |
Yes: 19-inch |
Wall-mounting |
No |
External USB flash memory |
1-GB USB flash-memory support |
Redundant power supply |
Same as for Cisco ASR 1002 |
Power input |
Same as for Cisco ASR 1002 |
Power consumption |
● Maximum (DC): 1020W ● Maximum (AC): 960W ● Maximum (out): 765W |
Airflow |
Front-to-back |
Operating temperature (nominal) |
32 to 104°F |
Operating temperature (short-term) |
32 to 122°F |
Operating humidity (nominal) (relative humidity) |
10 to 85% |
Operating humidity (short-term) |
5 to 90% |
Storage temperature |
-40 to 150°F (-40 to 70°C) |
Storage humidity (relative humidity) |
5 to 95% |
Operating altitude |
-500 to 10,000 feet |
Network Equipment Building Standards (NEBS) |
GR-1089 and GR-63 |
EMC standards |
● FCC 47 CFR Part 15 Class A ● VCCI Class A ● AS/NSZ Class A ● ICES-003 Class A ● EN55022/CISPR 22 Information Technology Equipment (Emissions) ● EN55024/CISPR 24 Information Technology Equipment (Immunity) ● EN300 386 Telecommunications Network Equipment ● (EMC) ● EN50082-1/EN61000-6-1 Generic Immunity Standard |
Safety Standard |
UL60950-1 CSA C22.2 No. 60950-1-03 EN 60950-1 IEC 60950-1 AS/NZS 60950.1 |
