ASR1004-20G-VPN/K9 Specification | |
General | |
Device Type | Router |
Enclosure Type | Desktop, rack-mountable - modular - 4U |
Connectivity Technology | Wired |
Performance | Forwarding performance: 23 Mbps ¦ Bandwidth: 20 Gbps |
Capacity | Access control entries: 100000 ¦ QoS hardware queues: 128000 ¦ Concurrent IPSec VPN tunnels: 10000 ¦ NAT/ firewall sessions: 2000000 ¦ GRE tunnels: 4000 ¦ Maximum number of instances: 4000 ¦ Concurrent RTP sessions: 4000 ¦ Concurrent L2TP VPN tunnels: 16000 ¦ Concurrent sessions: 32000 |
Network / Transport Protocol | IPSec |
Remote Management Protocol | SNMP, Telnet, SSH, CLI |
Features | NAT support, VPN support, load balancing, IPv6 support, Non-Stop Forwarding (NSF), Stateful switchover (SSO), Quality of Service (QoS), IPv4 support, NetFlow |
Compliant Standards | CISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03 |
Hard Drive | 40 GB |
Expansion / Connectivity | |
Interfaces | Management: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ Management: 1 x auxiliary - RJ-45 ¦ Management: 1 x USB - 4 pin USB Type A |
Expansion Slots | 1 (total) / 0 (free) x processor board ¦ 11 (total) / 9 (free) x expansion slot |
Installed Modules Qty (Max) | 3 (installed) / 12 (max) |
Power | |
Power Device | Internal power supply |
Power Redundancy | Yes |
Installed Qty | 2 (installed) / 2 (max) |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Rack Mounting Kit | Included |
Software / System Requirements | |
OS Provided | Cisco IOS Advanced Enterprise Services |
Dimensions & Weight | |
Width | 17.2 in |
Depth | 22 in |
Height | 7 in |
Manufacturer Warranty | |
Service & Support | Limited warranty - advance parts replacement - 90 days - response time: 10 days |
Environmental Parameters | |
Min Operating Temperature | 41 °F |
Max Operating Temperature | 104 °F |
Humidity Range Operating | 5 - 90% (non-condensing) |
